Aerial Platforms PLAP-35h

SIZE

Max.Working Height (A)

6.5m

8m

10m

12m

15.8m

Max.Platform Floor Height (B)

4.5m

6m

8m

10m

13.8m

Overall Lenght with Ladder (C)

1510mm

1850mm

2430mm

2430mm

2850mm

Overall Lenght  (D)

800mm

790mm

1210mm

1210mm

1310mm

Overall Height

2060mm

2200mm

2350mm

2470mm

2600mm

Overall Height Folding Fence(E)

1450mm

1680mm

1800mm

1930mm

2060mm

Platform Size Lenght/Width (F)

1340×750mm

1680×740mm

2270×1120mm

2270×1120mm

2700×1110mm

platform Extension size (G)

600mm

900mm

900mm

900mm

900mm

Wheel Base

1140mm

1390mm

1870mm

1870mm

2280mm

Ground Clearance Lowered/Raised

100/19mm

100/19mm

100/19mm

100/19mm

100/15mm

PARAMETER

Safe Working Load

230kg

230kg

450kg

320kg

230kg

S.W.L on Extension

110kg

110kg

113kg

113kg

110kg

Max. Working Number

2

2

4

3

2

minimum turing radius(inside/outside)

0.25m/1.4m

0.3m/1.75m

0m/2.4m

0m/2.4m

0m/2.4m

Lifting Motor

24V/1.3KW

24V/3.3KW

24V/4.5KW

24V/4.5KW

24V/4.5KW

Travel Speed Stowed/Raised

3.5/0.8km/h

3.8/0.8km/h

3.5/0.8km/h

3.5/0.8km/h

3.5/0.8km/h

Gradeability

25%

25%

25%

25%

25%

Max. Working Slope

X1.5°/Y3°

X1.5°/Y3°

X1.5°/Y3°

X1.5°/Y3°

X1.5°/Y3°

Wheels

φ254*76mm

φ305*114mm

φ381*127mm

φ381*127mm

φ381*127mm

Net weight

1050kg

1430kg

2350kg

2550kg

3670kg

POWER

Batteries

2×12V/160Ah

240/200Ah

240/200Ah

240/200Ah

4×6V/240Ah

Integrated Charger

24V/15A

24V/30A

24V/30A

24V/30A

24V/30A

Driver

Electric Driver

Hydraulic Driver

Hydraulic Driver

Hydraulic Driver

Hydraulic Driver
